IP65 Waterproof Nema 34 Stepper Motor 6.0A 8.5Nm(1203.97oz.in) – High Torque Waterproof Stepper for CNC and Automation
This IP65-rated Nema 34 stepper motor delivers 8.5Nm holding torque with 6.0A phase current. Built with a sealed housing, it ensures reliable operation in wet or dusty environments, making it ideal for CNC, robotics, and outdoor motion control systems.
IP65 Waterproof Nema 34 Stepper Motor 6.0A 8.5Nm(1203.97oz.in) – Durable & High Torque Stepper
Short Description:
This IP65 waterproof Nema 34 stepper motor offers powerful 8.5Nm (1203.97oz.in) holding torque and 6.0A phase current, designed for reliable performance in wet or dusty industrial environments. Ideal for CNC, automation, and outdoor motion control systems requiring high torque and waterproof protection.
Product Overview
The IP65 waterproof Nema 34 stepper motor has high torque with precise control. Featuring a sealed body to prevent water and dust ingress, it ensures stable operation in challenging conditions. With a 1.8° step angle and 6.0A current rating, this stepper motor is compatible with most industrial-grade stepper drivers and controllers.
Technical Specifications
| Item | Specification |
|---|---|
| Step Angle | 1.8° ±5% |
| Number of Phase | 2 |
| Phase Voltage | 3.0 VDC |
| Phase Current | 6.0 Amp |
| Phase Resistance | 0.5Ω ±10% (At 20°C) |
| Phase Inductance | 7.0 mH ±20% |
| Static Holding Torque | 8.5 Nm (1203.97 oz.in) |
| Insulation Class | Class B |
| Insulation Resistance | 100MΩ min. (500V DC) |
| Ambient Temperature | -20°C ~ +50°C |
| Ambient Humidity | ≤90% RH (non-condensing) |
| Motor Weight | Approx. 3.8 Kg |
| Voltage Range | DC 24–110V / AC 24–72V |
| Recommended Driver | OK28D72 or compatible 6A driver |
| Waterproof Rating | IP65 (Protected from dust and low-pressure water jets) |
| Use Environment | Cannot be used underwater; avoid steam or heavy condensation |
Excitation Sequence and Direction (Clockwise)
| Step | A+ | B+ | A- | B- |
|---|---|---|---|---|
| 1 | + | + | – | – |
| 2 | + | – | – | + |
| 3 | – | – | + | + |
| 4 | – | + | + | – |
Note: CW rotation is viewed from the mounting surface side.
Features & Advantages
- High torque performance up to 8.5Nm with 6.0A phase current
- IP65 waterproof housing protects against dust and splashes
- Compatible with NEMA 34 mounting and shaft standards
- Suitable for CNC machines, robotics, conveyors, and outdoor equipment
- Custom output shaft sizes available upon request
Applications
Widely used in CNC routers, laser cutters, automated packaging lines, and robotic positioning systems that require reliable, high-torque motion control. The waterproof feature makes it especially suitable for humid or outdoor environments.
Why Choose Our Waterproof Stepper Motor?
This waterproof Nema 34 stepper motor combines durability and accuracy, offering stable performance for demanding industrial tasks. Whether you need a high-torque stepper motor for automation or a sealed stepper motor for outdoor machinery, this IP65-rated model provides the ideal balance between power and protection.
